Pulp Machine
Low Density Cleaner
Low Density Cleaner is mainly used for removing heavy impurities in the pulp like gravel, scrap iron, dust, and large ink particles in the paper-making process.
Detail
Divided design, the cleaners can be divided into 3-4 parts, which makes it easier for disassembly, assembly, and replacement.
Different deslagging ways: open and closed type impurities discharge to meet different working environments.
Technical Data
| Model | KH-400 | KH-600 | KH-800 | KH-1000 | KH-1500 |
| Rate passing capacity of single equipment(L/min) | 400 | 600 | 800 | 1000 | 1500 |
| Inlet consistency(%) | 0.3-1 | 0.3-1.2 | 0.4-1.2 | 0.4-1.5 | 0.4-1.5 |
| Pressure of inflow pulp(Mpa) | 0.2-0.4 | 0.2-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
| Diameter of deslagging outlet(L/min) | 3-14 | 6-16 | 6-14 | 6-18 | 6-18 |
